Product Specification

• Category HWS801D
• General Information
• Series 800
• Type of Manufacturing OEM
• Platform(AV) MTK(MT8532) | ABOV
• # of Channel 3.1.2
• # of Speaker 10
• Total Power (W) 330W
• Reference THD 10%
• FRONT (MID/TW) (W) 20W x 2 + 10W x 2
• CENTER (MID/TW) (W) 20W x 2 + 10W x 1
• Effect Channel(TOP/SIDE/WIDE) 10W x 2
• Subwoofer Power (W) 200W
• Subwoofer Type Wireless
• Subwoofer model code PSWS801D
• Rearspeaker model code N/A
• Rear Surround Speaker Power (W) N/A
• Center Speaker Yes
• Upfiring Speaker Yes
• Sidefiring Speaker N/A
• Front Widefiring Speaker N/A
• Audio Feature
• Sound Modes Surround Sound expansion,
• Game Pro,
• Standard,
• Adaptive Sound
• DTS Virtual:X
• Voice enhance mode Yes
• Night mode Yes
• Spacefit sound(2.0) Yes
• Active Voice Amplifier(AVA) Yes
• Auto AV Sync Yes
• Dolby Dolby ATMOS
• Dolby TrueHD
• Dolby Digital Plus
• ATMOS Music
• DTS DTS 5.1ch
• LPCM 2ch
• Wireless Rear Speaker included N/A
• Wide Range Tweeter N/A
• Acoustic Beam Technology N/A
• HiRes Audio Decoding Yes
• Personal Listening Yes (Works with 9500S)
• Party Play Yes (Works with 9500S)
• Video Feature
• 4K Video Pass N/A
• HDR N/A
• Decoding Format
• MP3 Yes
• AAC Yes
• OGG Yes
• FLAC Yes
• WAV Yes
• ALAC Yes
• AIFF Yes
• Network
• Wireless Frequency Band 2.4 / 5GHz
• WiFi Spec 802.11ac
• WiFi Yes
• WiFi Region Code U
• Connectivity
• One Remote Control Yes
• USB Music Playback N/A
• HDMI In N/A
• HDMI Out 1
• HDMI ARC Yes(eARC)
• HDMI CEC Yes
• USB N/A(Only for Service)
• USB Version N/A(Only for Service)
• Bluetooth Yes
• Bluetooth Version 5.2
• Bluetooth Codec SBC
• Bluetooth Multi Connection N/A
• NFC N/A
• Bluetooth Power On Yes
• Auto Power Link N/A
• Digital Audio Input (Optical) 0
• Analog Audio Input N/A
• AirPlay Yes
• Chromecast Yes
• Spotify(HiFi) Connect Yes
• Tidal (HiFi) Connect Yes
• Roon Service N/A
• Wireless Dolby ATMOS Yes
• Dimension (WxHxD)
• Main Unit Size (Inch) 45.6 x 1.4 x 1.5
• Subwoofer Size (Inch) 9.3 x 9.4 x 9.3
• Rear Speaker Size (Inch) N/A
• Rear Speaker Wireless Module Size (Inch) N/A
• Package Size (Inch) 48.5 x 14.6 x 11.5
• Weight
• Set Weight 7.8
• Main Unit Weight (kg) 1.4
• Subwoofer Weight (kg) 6.4
• Rear Speaker Weight (kg) N/A
• Rear Speaker Wireless Module Weight (kg) N/A
• Package Weight (kg) 11.0
• Power Consumption
• Main Power Consumption (Standby) (W) 0.5W
• Subwoofer Power Consumption (Standby) (W) 0.5W
• Main Power Consumption (Operating) (W) 28W
• Power Consumption (Operating, Soundbar Only) (W) N/A
• Power Consumption (Operating, for TV, Max) (W) N/A
• Subwoofer Power Consumption (Operating) (W) 26W
• Main Free Voltage Yes
• Subwoofer Free Voltage Yes
• Rear Free Voltage N/A
• MAIN Power Adapter
• Subwoofer Power SMPS
• Rear Power N/A
• Rear Power Consumption (Standby) (W) N/A
• Rear Power Consumption (Operating) (W) N/A
• Adaptor Power 59W
• Energy Star Yes
• Accessory
• Remote Controller Yes (TM2261SIR,White)
• HDMI Cable Yes
• (Micro HDMI to HDMI)
• Optical Cable No
• Wallmount Kit Yes
• Battery for Remote Controller N/A
• Power Adapter Yes
• Rubber Foot N/A
• Zigbee/Thread Module N/A
• Customized ART Panel N/A
• Customized Color Bezel Yes
• Loading Quantity
• 20ft 252
• 40ft HC 640
• Special Feature
• Wall Mounting Yes
• Compatible rear speaker SWA9500S
• Compatible wireless Subwoofer inbox
• QSymphony (2024) Yes
• Multi position rear speaker N/A
• Farfield Voice expansion for TV Yes
• Stereo N/A
• Wired Group Play N/A
• Wireless Group Play N/A
• Group Play Yes
• Karaoke Mic In N/A
• Party Lighting N/A
• Bass Booster N/A
• DJ Effect N/A
• Karaoke N/A
• Waterresistant N/A
• Builtin battery N/A
• Battery type N/A
• Battery Life N/A
• Built in Wheel N/A
• SmartThings Hub/Matter Hub N/A
• Tap Sound Yes
• Voice Feature
• Works with Google Yes
• Alexa Builtin
• Bixby Builtin
• ETC
• Smart Things App Yes
• Builtin Demo Music (Shop Demo) Yes
• Shop Mode Yes
• Warranty card Yes
• Color White
• POP Label Yes
• Samsung Sound tower App (Bluetooth) N/A
